General Description
MCLRDT485 is the Sub-GHz applications, have good coverage and can provide wireless connections in a wide geographical area, which makes it possible to provide long-distance data transmission services in RS485 wireless data transmission.
This wireless technology has good anti-interference capabilities and can maintain stable data transmission in noisy environments. This makes it have good performance in RS485 wireless data transmission applications such as industrial automation, smart buildings, and smart transportation.
Features
Stable wireless communication: Long-distance, low-power consumption wireless communication technology
Network architecture: Supports various network architectures such as "single point to single point",
Group function: The same NETWORKID device can communicate with each other, providing better
Easy for system integration and application: In industrial environments, it can maintain a high level of stability
Economic benefits: Under long-term use, its high stability and long-distance transmission capabilities can
Specifications
NCC Certification.
Stable wireless communication: Long-distance, low-power consumption wireless communication technology
chip module, providing stable and reliable data transmission.
Network architecture: Supports various network architectures such as "single point to single point",
"single point to multipoint" and "multipoint to multipoint".
Group function: The same NETWORKID device can communicate with each other, providing better
information security.
Easy for system integration and application: In industrial environments, it can maintain a high level of stability
and reliability. It can be easily combined with customer-designed applications to provide greater flexibility.
Energy-saving design: Low consumption design can reduce power consumption.
Economic benefits: Under long-term use, its high stability and long-distance transmission capabilities can
greatly reduce maintenance and replacement costs.
Specifications
| Model | MC-LRDT485 |
| Frequency | 920~925 MHz |
| RF Output Power | 22 dBm (Max.) |
| RF sensitivity | -129 dBm |
| Communication interface | Setting: MicroUSB Communication: Modbus RTU RS485 |
| Adaptor | DC 5V/1A |
| Dimensions (excluding antenna) | 61 (L) x 82 (W) x 26 (H) mm |
| Power Consumption | 1 W (Max.) |
| Standard | 1. Adaptor 5V/1A 2. Antenna |
| Option | DIN Rail Clip |
